Description
When the going gets tough, it’s the Kubota R640 that gets tougher. Renowned durability, a robust 64.4 horsepower and commitment to operator comfort ensure that when you’re behind the wheel of the R640, you’re working at peak performance.
Specifications
Manufacturer
Kubota
Model
R640
Year
2025
Category
Loaders
Subcategory
Wheel Loaders
Emission Certification
Tier 4 Final
Output (SAE J1995 gross) HP (kW)/rpm
64.3 (48) / 2400
Output (SAE J1349 net) HP (kW)/rpm
61.1 (45.6) / 2400
Displacement (cu. in)
160 (2615)
Transmission Type
Hydrostatic transmission
Auxiliary Hydraulics Flow Rate (GPM)
17.8 (67.2)
Auxiliary Hydraulic Pressure (psi)
2973 (20.5)
Standard Tire Size
12.5-18
Traveling Speed: High (mph)
12.4 (20.0)
Traveling Speed: Low (mph)
3.0 (4.8)
Traction Force (lbs)
8588 (38.2)
Front/Rear Axle Traction Lock
Diff-lock (both axles)
Articulation Angle (deg.)
40 (each direction)
Angle of Rear Frame Oscillation (deg.)
±8
Loader Clearance Circle ft in (mm)
13ft 8in (4175)
Turning Radius Track Circle ft in (mm)
12ft 0in (3664)
Brakes (Service)
Enclosed wet disc
Tipping Load (Full Turn)
6526 (2960)/6812 (3090) / 5115 (2320)/5313 (2410)
Tipping Load (Straight)
7452 (3380)/7760 (3520) / 5820 (2640)/6063 (2750
Rated Operating Capacity (ROC)
3263 (1480)/3406 (1545) / 2558 (1160)/2657 (1205)
Standard Bucket Capacity (yd3)
0.94
Bucket Breakout Force (lbs)
9869 (43.9
Lifting Capacity at Ground Level lbs (kN)
8161 (36.3)
Loader Raise / Lower Time (sec.)
5.8 / 3.9
Fuel Tank (gal)
18.5 (70)
Hydraulic System (gal)
15.1 (57)
Hydraulic Reservoir (gal)
10.3 (39)
Operating Weight lbs (kg)
11177 (5070) / 11563 (5245)
Hinge Pin Height
10ft 8in
Dump Height at Fully Raised Position
8ft 3in
Maximum Dump Angle
45 degrees
Reach Fully Raised at Maximum Dump Angle
2ft 6in
Steering Angle
40 degrees
Frame Oscillation Angle
8 degrees
Overall Length
18ft 0in (5483)
Overall Width
5ft 11in (1800)
Overall Height
8ft 2in (2478) / 8ft 2in (2498)
Ground Clearance (in)
13in (330)
Engine
V2607
