Description
The M4 Series is the newest tractor to the M Series Family. The M4 tractors give small cattle/ hobby farmers the tools needed for quickly and efficiently completing a day's work. These tractors are packed with premium Cab features and built for operator comfort. The M4 Series will come in a Standard and two Deluxe models: M4D-061, M4-071 and M4D-071.
Specifications
Manufacturer
Kubota
Model
M4-061
Year
2025
Category
Tractors
Subcategory
Utility
PTO Type
Live-independent PTO, electro-hydraulic clutch with brake
PTO Speed rpm
540 / 540E
Tractor weight lbs (kg)
6008 (2725)
Engine
V3307-CR-TE4
Type (Make : KUBOTA)
4 cylinder in-line, Common Rail System, Direct Injection
No. of cylinders/Aspiration
4 / turbocharged
Engine gross power (97/68/EC) HP (kW)
65.4 (48.8)
PTO power (at rated engine rpm) HP (kW)
52 (38.8)
Total displacement cu in (cc)
203 (3331)
Rated engine RPM
2400
Fuel tank capacity gal (l)
2400
Alternator Amp
130
No. of speeds
F12 / R12 (option: F18 / R18 with Creep)
Main gear shift
Fully synchronized (6 speed)
Shuttle shift
Hydraulic-shuttle
Main clutch type
Multiple wet disc
Brake type
Hydraulic wet disc
Differential lock (Front / Rear)
Limited Slip Differential / Mechanical
4WD clutch type
Electro-hydraulic on-the-go
4WD system
Bevel gear type
Steering
Hydrostatic power steering
Overall length in (mm)
142(3600)
Overall width (minimum) in (mm)
75.6(1920)
Wheelbase in (mm)
84.1(2135)
Crop clearance (Front axle) in (mm)
18.1(460)
Tread width Rear in (mm)
56.2,68.7(1430,1744)
Turning radius (w/o brake) ft (m)
11.8 (3.6)
Overall height top of Cab in (mm)
101(2560)
Tread width Front in (mm)
58.5 (487)
Pump capacity (3-Point Hitch)gpm (l/Min)
16.7 (63.3)
3-Point Hitch
Telescopic lower link ends, Telescopic Stabilizers
Category
I / II
Control system
Position, draft (top link sensing) & mixed control
Lift capacity at 24 in behind lift point (ASAE)lbs (kg)
3307 (1500)
Cylinder type
Two external cylinders
No. of standard remote valves
2 (SCD / FD), Max 3
Cab
Deluxe Wide Cab
Front tire size
320 / 85R20
Rear tire size
420 / 85R30
