Description
Kubota's Grand L60 Series is the ultimate package for outstanding performance and maximum operator comfort in the 37-62 HP tractor segment. Premium in design and powerful in performance, the Grand L60 Series is equipped with high quality Kubota engines and transmissions. Whether you’re mowing, landscaping or needing front-mounted implements, Kubota has the versatility capabilities to match your needs. All of this is backed up with Kubota’s reputation for quality and durability, so you can maximize your productivity.
Specifications
Manufacturer
Kubota
Model
L5460 HST(4WD)
Year
2025
Category
Tractors
Subcategory
Compact
PTO Rear PTO Revolution
1 speed: 540 rpm
PTO Type
Independent
PTO Revolution
1 speed: 2000 rpm
Weight (with Rops)lbs (kg)
3990 (1810)
Lift capacity at 24 in behind lift point lbs(kg)
2976 (1350)
Type
Direct injection, vertical, water-cooled 4 cycle diesel
No. of cylinders / Aspiration
3 / Natural with EGR
Bore & stroke in (mm)
3.4 x 4.0 (87 x 102.4)
Total displacement cu in (cc)
148.5 (2434)
Battery
12V, RC: 133 min, 582A
Alternater
12V, 40A
Transmission
HST Plus (3 Ranges)
Steering
Hydrostatic power steering
Brake
Wet disc type
Travel speeds No. of speeds (at rated engine speed) mph (km/h) Forward H-DS L
L: 2.1 (3.4) ,M: 4.3 (7.0), H: 10.1 (16.2)
Travel speeds No. of speeds (at rated engine speed) mph (km/h) Forward H-DS H
L: 3.6(5.8) M: 7.3 (11.8),H:16.8 (27.1)
Travel speeds No. of speeds (at rated engine speed) mph (km/h) Reverse H-DS L
L:1.9 (3.1) ,M:3.9 (6.3), H: 9.1 (14.6)
Travel speeds No. of speeds (at rated engine speed) mph (km/h) Reverse H-DS H
L:3.2 (5.2) ,M:6.6 (10.6) ,H: 15.2 (24.4)
Engine gross power HP (kW)
56.0 (41.8)
Engine net power HP (kW)
54.0 (40.3)
PTO power HP (kW)
46.5 (34.7)
Rated speed rpm
2600
Overall length (w/o 3P) in (mm)
126.4 (3210)
Overall width (Min tread) in (mm)
67.3 (1710)
Overall height (w/Foldable Rops)in (mm)
98.0 (2490)
Wheelbase in (mm)
75.4 (1915)
Min ground clearance in (mm)
15.4 (392)
Tread Front(Front tire) in (mm)
52.8 (1340)
Min turning radius (w/brake, 4WD disengaged)feet (m)
9.2 (2.8)
Tread Rear(Rear tire) in (mm)
52.2 (1325), 56.3 (1430)
Fuel tank capacity US gal (l)
13.5 (51)
Implement pump GPM(l/Min)
9.4(35.6)
Power steering pump GPM(l/Min)
4.7(17.9)
Total hydraulic flow GPM(l/Min)
14.1(53.5)
3-point hitch
Category I & II
Standard the size''Front
9.5-16
Standard the size''Rear
14,9.26
