Description
Meet your new favorite piece of equipment: Kubota's Standard L Series takes power and performance to new heights. With a valuable combination of horsepower and high-quality construction, this feature-packed compact tractor is perfect for small property owners – starting with how much you’ll look forward to using it every day.
Specifications
Manufacturer
Kubota
Model
L2501-HST 4WD
Year
2025
Category
Tractors
Subcategory
Compact
PTO Rear PTO type
Live-continuous running
PTO PTO/Engine speed
540/2105
Weight (with Rops) lbs (kg)
2623(1190)
Type
Direct injection. Vertical, Water-Cooled 4 cycle diesel
Engine gross power HP (kW)
24.8 (18.5)
Engine net power HP (kW)
23.9 (17.8)
PTO power HP (kW)
19.0(14.2)
No. of cylinders
3
Bore & stroke in (mm)
3.4 x 3.6 (87 x 92.4)
Total displacement cu in (cm3)
100.47 (1647)
Rated speed rpm
2200
Battery
12V. RC: 123 min, CCA: 490 A
Alternator
12V, 40A
Fuel tank capacity US gal (l)
10.0 (38.0)
Transmission
Hydrostatic transmission,3 range speed
Steering
Integral type power steering
Brake
Wet disc type
Clutch
Dry type single stage
Traveling speed with standard AG tires
Forward 0 (0.0) - 11.5 (18.5),Reverse0(0.0) - 10.3 (16.6)
Overall length (w/o 3P) in (mm)
106.3 (2700)
Min ground clearance in (mm)
13.4 (340)
Tread Front tire in (mm)
43.8(1115) /47.1(1195) /50.8(1290)
Tread Rear tire in (mm)
43.1 (1095)
Min turning radius (w/brake. 4WD disengaged) feet (m)
7.9(2.4)
Overall width (Min tread) in (mm)
55.1(1400)
Overall height (w/Foldable Rops) in (mm)
91.7(2330)
Wheelbase in (mm)
63.3(1610)
Lift control type
Position control
Pump capacity (main)gpm (//min)
5.15 (19.5)
Pump capacity (PS)gpm (l/min)
3.13 (11.8)
3-point hitch
Category I
Litt capacity at lift points lbs (kg)
1918 (870)
Litt capacity 24 in behind lift points lbs (kg)
1389 (630)
System pressure PSI (MPa)
2205 (15.2)
Tire size Indust. Option Front/Rear
27 x 8.50. 15/15 - 19.5 R4
Tire size AG Standard Front/Rear
7.2 - 16/11.2 - 24
