Description
Meet your new favorite piece of equipment: Kubota's Standard L Series takes power and performance to new heights. With a valuable combination of horsepower and high-quality construction, this feature-packed compact tractor is perfect for small property owners – starting with how much you’ll look forward to using it every day.
Specifications
Manufacturer
Kubota
Model
L2501 Gear Drive Transmission-4WD
Year
2025
Category
Tractors
Subcategory
Compact
PTO Rear PTO type
Transmission driven with overrunning clutch
PTO PTO/Engine speed
540/1910
Weight (with Rops) lbs (kg)
2601(1180)
Type
Direct injection. Vertical, Water-Cooled 4 cycle diesel
Engine gross power HP (kW)
24.8 (18.5)
Engine net power HP (kW)
23.9 (17.8)
PTO power HP (kW)
20.5 (15.3)
No. of cylinders
3
Bore & stroke in (mm)
3.4 x 3.6 (87 x 92.4)
Total displacement cu in (cm3)
100.47 (1647)
Rated speed rpm
2200
Battery
12V. RC: 123 min, CCA: 490 A
Alternator
12V, 40A
Fuel tank capacity US gal (l)
10.0 (38.0)
Transmission
Gear shift, 8 forward and 4 reverse
Steering
Integral type power steering
Brake
Wet disc type
Clutch
Dry type single stage
Traveling speed with standard AG tires
Forward 0 (0.0) - 11.5 (18.5),Reverse 0(0.0) - 10.3 (16.6)
Overall length (w/o 3P) in (mm)
106.3 (2700)
Overall width (Min tread)in (mm)
55.1(1400)
Overall height (w/Foldable Rops)in (mm)
91.7(2330)
Min ground clearance in (mm)
13.4 (340)
Tread Front tire in (mm)
43.8(1115) /47.1(1195) /50.8(1290)
Tread Rear tire in (mm)
43.1 (1095)
Min turning radius (w/brake. 4WD disengaged) feet (m)
7.9(2.4)
Wheelbase in (mm)
63.3(1610)
Lift control type
Position control
Pump capacity (main)gpm (//min)
5.15 (19.5)
Pump capacity (PS)gpm (l/min)
3.13 (11.8)
3-point hitch
Category I
System pressurePSI (MPa)
2205 (15.2)
Litt capacity 24 in behind lift points lbs (kg)
1389 (630)
Litt capacity at lift points lbs (kg)
1918 (870)
Tire size Indust. Option Front/Rear
27 x 8.50. 15/15 - 19.5 R4
Tire size AG Standard Front/Rear
7.2 - 16/11.2 - 24
