Description
Bad Boy 4035 CH
Specifications
Manufacturer
Bad Boy
Model
4035 CH
Year
2026
Category
Tractors
Subcategory
Mid-Size Tractor
Engine
3 Cylinder, Water-Cooled, Diesel
Engine HP @ RPM
35
Displacement (in)
104.5
Number Of Cylinders
3
Fuel Tank (gal)
7.1
Total Hydraulic Flow (Power Steering + Implement)
12.6 (4.4+8.2)
Transmission
HST
Number Of Speeds
3 Range
Brakes
Wet, Multi-Disc
Type
Subframe-Mounted, Quick Attach
3-Point Hitch
Cat 1
Rear Remote Valve
Optional (Up To 2)
3-Point Hitch Lift Capacity @ 24" Behind Lift Point (lbs)
2,425
Weight
4035CH - 3,551 lbs
Rear (Mid) PTO Speed
540
PTO HP
29.5
Alternator
12 V, 50 A
IND (Front)
28X8.50-15
IND (Rear)
43X16.00-20
Breakout Force (lbs)
3,660
Shipping Weight (lbs)
1,270
Dig Force Bucket (lbs)
4,380
Overall Length
134.88"
Overall Width
4035CH - 55.6"
Overall Height
4035CH - 86"
Wheelbase
65.7"
Minimum Ground Clearance
13.1"
Standard Bucket Size (in)
16
Maximum Lift Height (in)
104
Dig Depth (in)
1.8
Lift Capacity To Full Height At Pivot Pin (lbs)
2,200
Maximum Dig Depth (in)
92.2
Battery
12 V, 540 CCA
