Description
From its beginnings as the L Series in 1967, to its evolution as the Standard L Series in 1997, Kubota’s popular compact tractor line has continued to build on its reputation for affordability, durability and versatility. Enhanced and refined over generations of models, The Standard L Series has earned its rightful position as the core of the Kubota compact tractor lineup and the top selling compact tractor in North America for more than 10 years†. †Based on EDA tractor sales data of under 40 horsepower models from 2009 to 2020.
Specifications
Manufacturer
Kubota
Model
L4802 Gear Drive Transmission 2WD
Year
2026
Category
Tractors
Subcategory
Compact
Rear PTO Type
Live independent PTO with hydraulic clutch
PTO/Engine Speed
540/2475
Transmission
Constant mesh with synchronizedshuttle 8 forward and 8 reverse
Clutch
Dry type single stage
Steering
Hydrostatic power steering
Brake
Mechanical, wet disc type
Traveling Speed with Standard AG Tires mph (km/h) Forward
1.4 (2.2) - 14.9 (24.0)
Traveling Speed with Standard AG Tires mph (km/h) Reverse
1.3 (2.1) - 14.3 (23.0)
Type
Direct injection, vertical, water-cooled 4-cycle diesel
Engine Gross Power* HP (kW)
48.4 (36.1)
Engine Net Power** HP (kW)
46.0 (34.3)
PTO Power HP (kW)
40.5 (30.2)
No of Cylinders
4
Bore & Strokein (mm)
3.4 × 4.0 (87 × 102.4)
Total Displacement cu in (cm3)
148.5 (2434)
Rated Speed rpm
2600
Battery
12V, RC: 120 min, CCA: 600 A
Alternator
12V, 45A
Fuel Tank Capacity US gal (ℓ)
13.5 (51)
AG Standard Front/Rear
7.5L - 15 / 14.9 - 24
Overall Length (w/o 3P) in (mm)
122.8 (3120)
Overall Width (min tread) in (mm)
62.2 (1580)
Overall Height (w/Foldable ROPS) in (mm)
91.7 (2330)
Wheelbase in (mm)
72.6 (1845)
Min Ground Clearance in (mm)
15.2 (385)
Tread Front Tire in (mm)
50.4 (1280) / 54.3 (1380) / 58.3 (1480) / 62.2 (1580)
Tread Rear Tire in (mm)
46.5 (1180) / 47.2 (1200) / 51.2 (1300) / 57.1 (1450) / 60.8 (1545)
Min Turning Radius (w/brake, 4WD disengaged) feet (m)
8.9 (2.7)
Weight (with ROPS) lbs (kg)
3296 (1495)
Lift Control Type
Position control
Pump Capacity (main) gpm (ℓ/min)
7.8 (29.4)
Pump Capacity (PS) gpm (ℓ/min)
4.7 (17.9)
3-Point Hitch
SAE Category I
Lift Capacity at Lift Points lbs (kg)
2870 (1300)
24 in behind Lift Points lbs (kg)
2320 (1053)
System Pressure kgf/cm2 psi
180 (17.7)
