Description
When you’re looking for comfort, practicality, and versatility, you can’t beat the experience that the new Kubota SVL75-3 gives you. The SVL75-3 replaces the popular SVL75-2 with a wide range of performance, comfort and productivity features. Still rated at 74.3 horsepower, but with a higher peak torque, the SVL75-3 is suited for whatever you throw in its way – digging, and moving materials, grading, landscaping, or hardscaping. Available as an open or closed cab, the SVL75-3’s side-screen to side-screen width of 36 inches means you’ll have plenty of room to stretch out, and a comfortable operator is a productive one.
Specifications
Manufacturer
Kubota
Model
SVL75-3
Year
2026
Category
Loaders
Subcategory
Track Loaders
Horsepower (gross)
74.3
Ground Pressure (psi)
Standard: 5.8/5.9 Wide: 4.7/4.8
Operating Weight lbs (kg)
9190 (4169) / 9420 (4273)
Operator Station
Open cab / closed cab
Rated Operating Capacity (ROC)
35 Percent Tipping Load lbs (kg): 2490 (1129)
Tipping Load lbs (kg)
7112 (3226)
Bucket Breakout Force lbf (kg)
6191 (2808)
Lift Arm Breakout Force lbf (kg)
4723 (2142)
Lift Arm Path
Vertical
Track Rollers (per side)
4
Traveling Speed: High mph (km/h)
8.6 (13.7)
Traveling Speed: Low mph (km/h)
5.6 (9.0)
Traction Force lbf (kgf)
9678 (4390)
Auxiliary Hydraulic Flow Rate Std/High Flow gpm (e/min) (GPM)
19.2 (72.7)/29.8 (112.8)
Auxiliary Hydraulics Flow Rate (GPM)
23.1/40
Ground Contact Pressure (psi)
Standard: 5.8/5.9 Wide: 4.7/4.8
Displacement cu in (cc)
203.2 (3331)
Overall Length
142.1 in (3609 mm)
Overall Height
81.8 in (2078 mm)
Overall Width
Vehicle Width Standard Track / Wide Track in (mm): 65.9 in (1675 mm) / 69.1 in (1755 mm), Width with Bucket in (mm): 68 in (1727 mm)
Track Width (standard/wide) in (mm)
12.6 in (320 mm) / 15.8 in (400 mm)
Track Ground Contact Length
56.5 in (1436 mm)
Ground Clearance
11.7 in (296 mm)
Height to Hinge Pin
122.7 in (3117 mm)
