Description
Kubota U17-5
Specifications
Manufacturer
Kubota
Model
U17-5
Year
2025
Category
Excavators
Subcategory
Compact Excavators
Engine Model
Kubota D902 - E4 - BH - 6EU
Horsepower (gross)
16.1
Displacement
54.8 cu in
Pump Capacity
4.6 ( 17.3 ) GPM ( LPM )
Auxiliary Hydraulics Flow Rate
7.3 ( 27.7 ) GPM ( LPM )
Hydraulic Oil Reservoir / System
3.4 ( 13 ) /5.8 ( 21.8 ) gal ( 1 )
Overall Length
11 ft 7.7 in ( 3550 )
Overall Height
7 ft 9.3 in ( 2370 )
Overall Width
3 ft 3.4 in ( 1000 ) / 4 ft 3.2 in ( 1300 )
Min Ground Clearance
6.1 in ( 155 )
Crawler Length
5 ft 2.2 in ( 1580 )
Blade Width
4 ft 3.2 in ( 1300 ) / 3 ft 3 in ( 990 )
Blade Height
10.2 in ( 260 )
Bucket Breakout Force
15.8 kN ( 1609 ) lbs ( kgf )
Arm Breakout Force
8.7 kN ( 887.2 ) lbs ( kgf )
Traveling Speed: High
2.7 ( 4.4 ) mph ( kph )
Traveling Speed: Low
1.4 ( 2.3 ) mph ( kph )
Fuel Reservoir
5.3 ( 13 ) gal ( 1 )
Ground Contact Pressure
4.0 ( 0.29 ) psi , kgf ( cm2 )
Operating Weight
3902 ( 1770 ) lbs ( kg )
