Description
Kubota-SVL50x
Specifications
Manufacturer
Kubota
Model
SVL50x
Year
2025
Category
Loaders
Subcategory
Track Loaders
Overall Length, in (mm)
117.6 (2980)
Overall Height, in (mm)
76.5 (1940)
Overall Width, in (mm)
48.5 (1230)
Track Width (standard/wide), in (mm)
11.8 (299)
Track Ground Contact Length, in (mm)
48.9 (1140)
Ground Clearance, in (mm)
8.3 (211)
Height to Hinge Pin, in (mm)
101.6 (2580)
Horsepower (gross)
49.6
Displacement cu in (cc)
111.4 (1826)
Auxiliary Hydraulic Pressure, psi (bar)
3000 (206.8)
Auxiliary Hydraulics Flow Rate, GPM (LPM)
20 (75.7)
Operating Weight, lbs (kg)
5620 (2549)
Operator Station
Closed Cab
Rated Operating Capacity (ROC), lbs (kg)
35% Tipping Load: 1176 (533)
Tipping Load, lbs (kg)
3360 (1524)
Bucket Breakout Force, lbf (kg)
4900 (2223)
Lift Arm Breakout Force, lbf (kg)
3560 (1615)
Lift Arm Path
Radial
Ground Contact Pressure, psi (kPa)
4.9 (33.8)
Track Rollers (per side)
4
Traveling Speed: High, mph (kph)
9.9 (15.9)
Traveling Speed: Low, mph (kph)
4.9 (7.8)
Ground Pressure, (psi)
4.9
