Description
When the going gets tough, it’s the Kubota U48-5 that gets tougher. Rated at 40.4 horsepower and featuring a 9304 pound breakout force, the Kubota compact excavator assists you in the toughest jobs on the lot and the optional keyless start, rear view camera and KubotaNOW telematics are ready to help you achieve success. Factor in an optional hydraulic angle blade and the U48-5 is ready to help you break new ground and get the job done!
Specifications
Manufacturer
Kubota
Model
U48-5
Year
2025
Category
Excavators
Subcategory
Compact Excavators
Engine Model
D1803-CR-TE5-BH3
Horsepower (gross)
40.4 / 2200
Displacement (cu. in)
111.4
Min Ground Clearance
12ft (310)
Pump Capacity (GPM)
31.4 (118.8)
Auxiliary Hydraulics Flow Rate (GPM)
17.2 (65.0) / 9.8 (37)
Bucket Breakout Force (lbs)
9304 (4220)
Arm Breakout Force (lbs)
5304 (2406)
Traveling Speed: High (mph)
3.0 (4.9)
Traveling Speed: Low (mph)
1.7 (2.8)
Ground Contact Pressure (psi)
Ground Contact Pressure (psi): Rubber: 4.0 (0.284) / 4.1 (0.289), Angle blade rubber: 4.2 (0.296) / 4.3 (0.302), Steel: 4.1 (0.290) / 4.2 (0.295), Angle blade steel: 4.3 (0.302) / 4.4 (0.307)
Hydraulic Oil Reservoir / System
10.6 (40) / 20.1 (76)
Fuel Reservoir
17.4 (66.0)
Operating Weight lbs (kg)
Operating Weight lbs (kg): Rubber: 10848 (4920) / 11057 (5015), Angle blade rubber: 11322 (5135) / 11531 (5230), Steel: 11134 (5050) / 11342 (5145), Angle blade steel: 11608 (5265) / 11818 (5360)
Overall Length
17ft 7in (5355)
Overall Height
8ft 4in (2550)
Overall Width
6ft 5in (1960)
Crawler Length
8ft 2in (2500)
Blade Width
6ft 5in (1960)
Blade Height
1ft 4in (410) / Angle blade: 1ft 5in (425)
