Description
When you have to take on a tough job in a tight space, look no further than the versatile U Series. Kubota U Series excavators offer performance, durability, convenience and comfort to help you tackle tougher jobs in even tighter spaces.
Specifications
Manufacturer
Kubota
Model
U35-4
Year
2025
Category
Excavators
Subcategory
Compact Excavators
Model
U35-4
Type of Rops
Canopy
OPG (Top Guard Level I)*
Cab
Type of tracks
Rubber / Steel
Swing system(Unit swing speed)
8.9 rpm
Swing system(Boom swing angle)(Left)
71 degree
Swing system(Boom swing angle)(Right)
45 degree
Blade(Max lift above ground)
14.65 in
Blade(Max drop below ground)
14.53 in
Operating weight ((Including operator’s weight @ 175 lbs))(Rubber) (Canopy)
3687 kgf
Operating weight ((Including operator’s weight @ 175 lbs))(Rubber) (Cab)
3833 kgf
Operating weight ((Including operator’s weight @ 175 lbs))(Steel) (Canopy)
3776 kgf
Operating weight ((Including operator’s weight @ 175 lbs))(Steel) (Cab)
3922 kgf
Operating Weight(lbs)
8488
Rear Swing Clearance
2"
Hydraulic Hammer (ft/lb)
500
Pin-On Buckets
12-24"
Quick Attach Buckets
12-36"
Quick Coupler
Mechanical
Steel Tracks
11.8"
Model
Kubota D1703M-DI-E4
Output (SAE J1995 gross)
2200 rpm
Output (SAE J1349 net)
2200 rpm
Displacement
1647 cc
Fuel reservoir
46.9
Engine Type
D1703M-DI-E4 3-cylinder, Tier 4
Horsepower (gross)
24.8
Displacement (cu. in)
100.5
Dimensions(Overall length)
15'7" ft in
Dimensions(Overall height)
8'1.2 ft in
Dimensions(Overall width)
5'6.9" ft in
Dimensions(Min ground clearance)
11.34 in
Blade(Dimensions)(Width)
5'6.9" ft in
Blade(Dimensions)(Height)
1'1.5" ft in
Overall Length (transport)
15'7"
Overall Height
8'1.2"
Overall Width
5' 6.9"
Maximum Digging Depth
9' 8.9"
Maximum Dumping Height
11' 0.7"
Hydraulic system(Pump capacity )
5.5 (20.9) x 1 /min
Hydraulic system(Auxiliary hydraulic flow)(AUX1)
60 /min
Hydraulic system(Max breakout force)(Bucket)
3594 kgf
Hydraulic system(Max breakout force)(Arm)
2019 kgf
Hydraulic oil (Hydraulic oil (Reservoir)
44.6
Hydraulic oil (Hydraulic oil (System)
61
Pump Capacity (GPM)
26.5
Auxiliary hydraulic flow
15.8
Bucket Breakout Force (lbs)
7924
Drive system(Travel speed)(Low)
3.0 km/h
Drive system(Travel speed)(High)
4.6 km/h
Drive system(Max traction force)(Low speed)
2763 kgf
Drive system(Tumbler distance)
5'6.5" ft in
Drive system(Crawler length)
6'10" ft in
Drive system(Shoe width)(Rubber)
11.8 in
Drive system(Ground contact pressure)(Rubber)(Canopy)
0.34 kgf/cm2
Drive system(Ground contact pressure)(Rubber)(Cab)
0.36 kgf/cm2
Drive system(Ground contact pressure)(Steel)(Canopy)
0.35 kgf/cm2
Drive system(Ground contact pressure)(Steel)(Cab)
0.36 kgf/cm2
Maximum Traveling Speed (mph)
1.9/2.9
Ground Contact Pressure(psi)
5.10
