Description
Get down to bedrock with these powerhouse excavators. Kubota’s compact excavators combine maneuverability, power and reliability with economy to help you haul away more pay dirt on every job. These machines have earned high market acclaim for outstanding utility and exceptional, efficient operation.
Specifications
Manufacturer
Kubota
Model
KX71-3S
Year
2025
Category
Excavators
Subcategory
Compact Excavators
Blade Max drop below ground
12''(310)
Blade Max lift above ground
1'1"(340)
Swing system Boom swing angle Left / Right
80 / 60
Swing system Unit swing speed
9.4
Blade Dimensions Width / Height
4'11''(1500) / 12'' (300)
Min ground clearance
11''(285)
Operating weight Including operator’s weight 175 lbs
6305 / 6550 (2860 / 2970)
Overall height Canopy / Cab
8'(2430) / 7'11'' (2410)
Overall length
14'11''(4550)
Overall width
4'11''(1500)
Displacement
91.4(1498)
Model
V1505-BH
Output(SAE J1995 gross)
24.4 (18.2) / 2250
Output(SAE J1349 net)
23.1 (17.2) / 2250
Fuel reservoir
11.9(45)
Hydraulic oil (reservoir/system)
9.0(34) / 13.2 (50)
Hydraulic system Auxiliary hydraulic flow
13.1(49.5)
Hydraulic system Max breakout force Bucket / Arm
6350(2880) / 3285 (1490)
Hydraulic system Pump capacity
8.32(31.5) Piston x 2 / 4.76 (18.0) Gear x 1
