Description
When you have to take on a tough job in a tight space, look no further than the versatile U Series. Kubota U Series excavators offer performance, durability, convenience and comfort to help you tackle tougher jobs in even tighter spaces.
Specifications
Manufacturer
Kubota
Model
U27-4
Year
2025
Category
Excavators
Subcategory
Compact Excavators
Type of Rops/FOPS
Canopy / Cab
Type of tracks
Rubber
Drive system Travel speed (Low / High) mph (km/h)
1.6 (2.6) / 2.7 (4.3)
Drive system Max traction force (Low speed) lbs (kgf)
6767 (3069)
Swing system Unit swing speed rpm
9.9
Operating weight (Includes operator weight 175lbs) (Canopy Rubber / Steel) lbs (kgf)
5688 (2580)
Operating weight (Includes operator weight 175lbs) (Cab Rubber / Steel) lbs (kgf)
5908 (2680)
Dimensions Overal length ft in (mm)
13'6" (4100)
Dimensions Overall height (Canopy / Cab) ft in (mm)
7'11" (2420) / 7'10" (2400)
Dimensions Overall width ft in (mm)
4'11" (1500)
Dimensions Min ground clearance in(mm)
12.1 (307)
Drive system Tumbler distance ft in (mm)
5'1.4" (1560)
Drive system Crawler length ft in (mm)
6'6.3" (1990)
Drive system Shoe width (Rubber / Steel) in(mm)
11.8 (300)
Boom swing angle (Left / Right) degree
75 / 55
Blade Dimension (Width) ft in (mm)
4'11" (1500)
Blade Dimension (Height) ft in (mm)
11.8" (300)
Blade Max lift above ground in(mm)
14.2" (360)
Blade Max drop below ground in(mm)
12.6" (320)
Max digging height ft in (mm)
14'6" (4420)
Max dumping height ft in (mm)
10'0" (3040)
Max digging depth ft in (mm)
9'5" (2870)
Max vertical digging depth ft in (mm)
7'8" (2340)
Max digging radius, at ground level ft in (mm)
15'4" (4680)
Max digging radius ft in (mm)
15'9" (4790)
Min turning radius (W/o swing) ft in (mm)
6'6" (1970)
Min turning radius (With swing) ft in (mm)
5'1" (1539)
Min tail turning radius ft in (mm)
2.7" (790)
Engine Model
Kubota D1105-BH
Engine Output (SAE J1995 gross) HP (kW)/rpm
20.8 (15.5) / 2400
Engine Output (SAE J1349 net) HP (kW)/rpm
20.0 (14.9) / 2400
Engine Displacement cu in (cc)
68.5 (1123)
Hydraulic system Pump capacity gpm ( /Min)
7.6 (28.8) × 2 / 5.1 (19.2) × 1
Hydraulic Auxiliary hydraulic flow gpm ( /Min)
12.7 (48)
Hydraulic Max breakout force (Bucket / Arm) lbs (kgf)
7014 (3180) / 2777 (1260)
Drive system Ground contact pressure (Canopy) psi (kgf/cm2)
3.321 (0.234)
Drive system Ground contact pressure (Cab) psi (kgf/cm2)
3.481 (0.245)
Hydraulic oil (reservoir / system) gal (l)
5.8 (22) / 9.7 (37)
Fuel reservoir gal (l)
8.7 (33)
